| Model |
LH1001T60100S |
LH1001T60200S |
LH11X5T60100S |
LH11X5T60200S |
LH1002T60200S |
LH1003T60200S |
LH1003T60400S |
| Capacity |
1kVA |
1kVA |
1.5kVA |
1.5kVA |
2kVA |
3kVA |
3kVA |
| Technical Specification |
| UPS Topology |
Line-Interactive |
| Display Method |
LCD + LED |
| Display Content |
Input/Output Voltage, Battery Voltage, Battery Capacity, Load Capacity, Machine Operating Mode, Frequency |
| Battery Reversal |
Optional |
| Output Short Circuit Protection |
AC Mode: Jump Fuse; Inverter Mode: Shut Down |
| Low DC Voltage Protection |
Inverter Shut Down Automatically, Once AC Recovers, Inverter Turns On and Charges Automatically |
| Over Temperature Protection |
Unit Automatically Starts Charging When Mains Power Restores |
| Overload Protection |
105% Alarm, 110% Shutdown after 60s, 130% Shutdown after 20s, 200% Shutdown after 1s |
| USB Output |
DC 5V/1A ×1 + 5V/2A ×1 (Optional) |
| Communication |
RS232 Standard, USB/RS485/SNMP (Optional) |
| Temperature |
-10°C ~ 50°C |
| Humidity |
15% - 93% Non-Condensing |
| Input Specification |
| Input Voltage |
100/110/120/127/220/230VAC (+25%, -36%) |
| High AC Voltage Protection |
Turn Off AC, Switch to Inverter Automatically |
| Frequency |
50Hz / 60Hz ± 2.5Hz |
| Input/Output Connector |
Input Power Cable, 2pcs Output Sockets |
| Output Specification |
| Output Voltage |
100/110/120/127/220/230VAC (AC Mode ±10%, Battery Mode ±5%) |
| Transfer Time |
4ms / 8ms (Optional) |
| Output Frequency |
50Hz / 60Hz ±0.5Hz |
| Wave Form |
Pure Sine Wave |
| AC Efficiency |
93% |
| Battery Efficiency |
81% |
| Battery Specification |
| Battery Voltage |
12VDC |
24VDC |
48VDC |
| Charging Current |
1-20A Adjustable |
1-40A Adjustable |
| Battery Connector |
Terminals |
| Physical Specification |
| Machine Size (W×D×H mm) |
381 × 145 × 210 |
| Package Size (W×D×H mm) |
470 × 230 × 315 |
| Net Weight (Kg) |
6.9 |
7.3 |
8.1 |
16.3 |
18.8 |
18.5 |
21.5 |
| Gross Weight (Kg) |
7.9 |
8.3 |
9.1 |
17.6 |
20.1 |
19.8 |
22.8 |
